NPK Linear Vibrating Screen

NPK Linear Vibrating Screen

Introduction

Linear Vibrating Sifter Sieve are very useful in pharmaceutical, plastics, rubber, ceramic, food, chemical, fertilizer, glass industries.Linear Vibrating Sifter Sieve can be provided with dust proof cover as required. It can be supplied of different sizes depending on capacity required.Inlets, outlets and legs can be customized to fit your installation requirements.

Overview:

Quick details:

Condition: New

Place of origin: Shanghai, China

Voltage: 380/220/415/ customized

Certification: CE, ISO, ATEX.

Application: Chemical, food, sand, etc.

Applicable industry: Building material shops, manufacturing plant, food & beverage......

Layers: 1-4 deck screen of new linear vibrating screenSurface treatment: polishing/sand blast/ paint

Noise: ≤75d(B)A

Speed: 960rpm/min

Warranty: One year

Brand name: Navector

Type: Linear Weight: 850kg

Dimension(L*W*H): 2000*1000*1690mm

Motor power: 2*(0.4kw~1.5kw)

Material: carbon steel/stainless steel

Capacity: required

After-sale service: 7*24hrs*365

Driven by two contra-rotating vibrators the linear action produces a positive conveying action capable of vibrating larger and inclined screens suitable for wet and difficult materials. Typical applications include Grading, Washing and De-watering.

· Screen sizes up to 5m long x 2m wide

· Mild or stainless steel construction

· Open, semi or fully enclosed using bolt-on or quick release covers

· Single or multiple decks

· Screen media options include: woven wire, perforated plate, polyurethane, rubber, wedge wire, bars, fingers or tines

· Automatic mesh cleaning systems

· High temperature or ATEX applications

Lined with hardened steel, stainless steel, plastic, rubber or other specialist coatings

Application:
